变化速率ROC的python实现过程

quant001

OC(Price Rate of Change)又称变动率指标，乃以今天的收盘价比较其N天前的收盘价的差除以N天前的收盘（本质其实是N日K线的涨幅），以比率表示之，此指标经由Gerald Apple 和 Fred Hitschler 两人于”Stock Market Trading Systems”一书中介绍，采用12天及25天周期可达到相当的效果。

计算公式

(close-ref(close,N))/ref(close,N)*100

1. # Rate of Change code

2.

3. # Load the necessary packages and modules

4. import pandas as pd

5. import pandas.io.data as web

6. import matplotlib.pyplot as plt

7.

8. # Rate of Change (ROC)

9. def ROC(data,n):

10. N = data['Close'].diff(n)

11. D = data['Close'].shift(n)

12. ROC = pd.Series(N/D,name='Rate of Change')

13. data = data.join(ROC)

14. return data

15.

16. # Retrieve the NIFTY data from Yahoo finance:

17. data = web.DataReader('^NSEI',data_source='yahoo',start='6/1/2015',end='1/1/2016')

18. data = pd.DataFrame(data)

19.

20. # Compute the 5-period Rate of Change for NIFTY

21. n = 5

22. NIFTY_ROC = ROC(data,n)

23. ROC = NIFTY_ROC['Rate of Change']

24.

25. # Plotting the Price Series chart and the Ease Of Movement below

26. fig = plt.figure(figsize=(7,5))

27. ax = fig.add_subplot(2, 1, 1)

28. ax.set_xticklabels([])

29. plt.plot(data['Close'],lw=1)

30. plt.title('NSE Price Chart')

31. plt.ylabel('Close Price')

32. plt.grid(True)

33. bx = fig.add_subplot(2, 1, 2)

34. plt.plot(ROC,'k',lw=0.75,linestyle='-',label='ROC')

35. plt.legend(loc=2,prop={'size':9})

36. plt.ylabel('ROC values')

37. plt.grid(True)

38. plt.setp(plt.gca().get_xticklabels(), rotation=30)


复制代码
